Product Description
12V 6.5Ah Sealed Lead Acid Battery with F2 Terminals - Length: 151mm (5.94") / Width: 51mm (2.01") / Height: 95mm (3.74")
| 12V 6.5Ah Sealed Lead Acid Rechargeable Battery | |
| Model: TLV1265F2 | |
| Terminals: F2 - 0.250" | |
| Length: 151mm (5.94") / Width: 51mm (2.01") / Height: 95mm (3.74") | |
| High Performance |
Features of the TLV1265F2 - 12V 6.5Ah Sealed Lead Acid Battery with F2 - 0.250 terminals
• Absorbent Glass Mat (AGM) technology for efficient gas recombination of up to 99% and freedom from electrolyte maintenance or water adding
• Not restricted for air transport-complies with IATA/ICAO Special Provision A67
• UL-recognized component
• Can be mounted in any orientation
• Computer designed lead, calcium tin alloy grid for high power density
• Long service life in float or cyclic applications
• Maintenance-free operation
• Low self discharge
Applications
• UPS Standby Power Applications
• Data Centers
• Emergency 911 Centers
• Hospitals & Medical Applications
• Military Power Equipment
• Emergency Lighting
• Fire Detection and Alarm Devices
Product Specifications
Dimensions
Terminal Type: F2 - 0.250"
Length (mm/inch): 151/5.94
Width (mm/inch): 51/2.01
Height (mm/inch): 95/3.74
Total Height (mm/inch): 101/3.98
Approx. Weight (kg/lbs): 1.9/4.19
Performance Characteristics
Nominal Voltage: 12V
Nominal Capacity 77ºF (25ºC)
20HR (10.5V): 6.5Ah
10HR (10.5V): 6Ah
1HR (9.60V): 4.23Ah
Internal Resistance
Fully Charged battery 77ºF(25ºC): Approx. 24mΩ
Capacity Affected by Temperature (20 Hour)
40°C: 102%
25°C: 100%
0°C: 85%
-15°C: 65%
Self-Discharge (25°C)
3 Month: Remaining Capacity: 91%
6 Month: Remaining Capacity: 82%
12 Month: Remaining Capacity: 65%
Nominal Operating Temperature:
25°C±3°C (77°F±5°F)
Operating Temperature Range
Discharge: -15°C～50°C(5°F～122°F)
Charge: -10°C～50°C(14°F～122°F)
Storage: -20°C～50°C(-4°F～122°F)
Float Charging Voltage (25°C):
13.60 to 13.80V Temperature compensation: -18mV/°C
Cyclic Charging Voltage (25°C):
14.50 to 14.90V Temperature compensation: -30mV/°C
Maximum Charging Current: 1.95A
Maximum Discharge Current: 97.5A (5 sec)
Terminal Material: Copper
Designed Floating Life: 10 Years
